alpha:ONE

High quality industrial multipurpose automation board for real time applications.

• STM32F722 32bit micro-controller
• 6-36V supply input
• 12x 24V isolated digital inputs
• 6x 24V / 32A power outputs
• 21x 3.3V multi-function pins (GPIO/PWM/ADC/DAC/UART/SPI/I2C)
• 10/100 Mbit Ethernet
• 1x CAN Bus
• 1x switchable RS232 or RS485 half-duplex
• 2x RS422/485 full-duplex
• microSD card slot (up to 32 Gb)
• Real time clock with battery backup
• Euro card 160x100x23mm
